Cotton Canvas Conveyor Belts

¡î Product application: It is suitable for middle and long distance conveying of materials, such as coal, ore stone or other product under high load, speed ,impact and heavy wear.

¡î Product characteristics: Nylon canvas is a fine synthetic fiber used in the rubber industry. It has an enormous advantage of good in elasticity and wearing resistance. Nylon canvas conveyor belt is characterized by high adhesion, good flexing capacity, good trough ability, high strength, as well as good resistance to moisture and heat, thus it has a long lasting service life.

Specification and technical data of nylon canvas conveyor belts:

Fabric type

NN-100

NN-150

NN-200

NN-250

NN-300

NN-400

Cloth thickness £¨ mm £©

1.10

1.15

1.20

1.30

1.40

1.50

Longitudinal

full thickness tensile strength (KN/m)

3 plies

300

450

600

750

900

1200

4 plies

400

600

800

1000

1200

1600

5 plies

500

750

1000

1250

1500

2000

6 plies

600

900

1200

1500

1800

2400

7 plies

700

1050

1400

1750

2100

2800

8 plies

800

1200

1600

2000

2400

3200

Fabric adhesion (N/mm)

¡Ý 4.5

Longitudinal elongation

¡Ü 4%

Width (mm)

400 ~ 1600

Rubber thickness (mm)

Top

1.5 ~ 8

Bottom

0 ~ 4.5

Length (m/roll)

¡Ü 200mm

¡Ü 250mm

¡¡
